Double-blade mining machine Chain Type
Home - Products - Double-blade Mining Machine - Double-blade mining machine Chain Type
1.It has a compact structure, with mechanical system, hydraulic system and electrical system integrated, high degree of automation, simple operation and easy-to-use feature.
2.The cylindrical guide rail is fully sealed to ensure that the guide rail no pollution and machine has an original lubrication system, so the service life and utilization ratio are effectively increased and maintenance times and costs are reduced. It is a mine quarrying machine with significantly increased comprehensive benefits.
3.Unique cylindrical guide, hydraulic elevator design and super wide chassis, so the structure is more stable and longer useful life.
4.With the super giant saw blades, it can be used for the processing of ultra-large rocks and blocks to improve out turn percentage of the mine and make full use of the mineral resource.
5.Disc saw blades cutting is more secure, environmental, lower cost and more efficient than traditional blasting mining method.
2.The cylindrical guide rail is fully sealed to ensure that the guide rail no pollution and machine has an original lubrication system, so the service life and utilization ratio are effectively increased and maintenance times and costs are reduced. It is a mine quarrying machine with significantly increased comprehensive benefits.
3.Unique cylindrical guide, hydraulic elevator design and super wide chassis, so the structure is more stable and longer useful life.
4.With the super giant saw blades, it can be used for the processing of ultra-large rocks and blocks to improve out turn percentage of the mine and make full use of the mineral resource.
5.Disc saw blades cutting is more secure, environmental, lower cost and more efficient than traditional blasting mining method.
（Swipe left to see more）
| Name | Unit | YZK-1360/1900 | YKZ-1500/2000 | YZK-1950/2450 | YZK-2600/3100 |
| Diameter of blade | mm | φ2200*2-φ3600*2 | φ2200*2-φ3600*2 | φ2200*2-φ4800*2 | φ2200*2-φ4800*2 |
| Max cutting depth | mm | 1550 | 1550 | 2150 | 2150 |
| Scope of cutting width | mm | 1360-1900 | 1500-2000 | 1950-2450 | 2600-3100 |
| Water consumption | m³/h | 5 | 5 | 5 | 5 |
| Power of main-drive | kw | 45/55*2 | 45/55*2 | 55/65*2 | 55/65*2 |
| Total power | kw | 98.5/118.5 | 98.5/118.5 | 118.5/138.5 | 118.5/138.5 |
| Center distance of rail | mm | 1140 | 1290 | 1670 | 2200 |
| Overall dimension (L*W*H) | mm | 3550*1450*2850 | 3550*1600*2850 | 5200*2100*3600 | 5200*2700*3600 |
| Approximate weight | kg | 7500-8500 | 7500-8500 | 10000-11000 | 11000-12000 |
